30% savings for Bethune University
| A Case Study

Introducing Our Partner

We were recently contacted by one of our US distributors, who claimed that a significant cost reduction had been achieved within just four weeks. BEST decided to send their Sales Director Ben Willcocks and Media Manager Steve Hill over to evaluate the results.

The Problem

It emerged that Bethune University was originally attracted to the Eniscope as a means to illustrate an irregularity in the power supply coming in from the utility transformer.

The University had experienced many power surges over the past several years which cost them $10,000 per occurrence in blown water pumps and circuit boards.

The Utility Company had been called out to evaluate the problem on several occasions and had always concluded that the surge must have been generated by a lightning strike and that the transformer was not in any way faulty.
So BEST we’re contacted and Eniscope was installed to record the next power surge. It was hoped that it would happen on a clear day, so the Utility Provider couldn’t blame the weather.
However, within days of the installation, Eniscope was able to diagnose the root of problem which gone undetected for an incredible five years!

The Approach

The Solution

When the original water chilling equipment was installed, the system was set to perform an automatic system shut down when the chiller reached a certain minimum load. The campus engineer was unaware of this setting.

The Eniscope revealed that when the call for cold air across the campus was minimal, usually in the late night and the early hours of the morning, the system was actually shutting itself down and then restarting a few hours later. This caused a massive energy spike at each start up and undue wear and tear on the 30 and 50 hp pumps being used to move the cold water from one building to the next.

Our Distributor brought this information to the attention of campus engineers. In turn they were then able to work with the chiller equipment service company to tweak the equipment settings and avoid the late night shut downs and subsequent full system start ups. This generated savings of over 30% per month in that building alone.

This example clearly illustrates that you can not place a value on energy data until it has been acquired and evaluated. In this case, the energy data was instrumental in identifying a real problem which was ultimately a very simple “no cost” adjustment to correct.

The Proof of Concept

Jesper and the team installed Eniscope at four locations considered ‘typical’ of the full portfolio.

26,500 kilowatt hours saved
8,480kg of carbon dioxide saved
13% energy and cost savings
Payback period of 19 months
The raw results

In terms of raw figures, the full rollout equates (so far) to some incredible savings.

12% average cost saving
864 tonnes of carbon dioxide saved
2.7m kilowatt hours saved
Following such a considerable success, Reitan are now looking at similar projects for 7-Eleven stores in Sweden and Norway.

Looking to the future
